EM0032-EM0037/EP0045 Rix EASI/O Series 2 System:
More Details:
This system replaces the SIO cables used in your Atari devices. You open each device, unsolder the SIO jack(leave the second jack if desired), then solder in the EASI/O S2 Jack board. Reassemble your device. Move to the next one.

Show me how to connect.HERE.

Connecting the devices is very easy. Just plug in a standard Ethernet cable into the Right/Black RJ45 jack. This works with most devices available. A few require the lesser used lines, so make it the first in the chain and connect another cable to the Left/RED jacks.

And best of all, there is no such thing as a dead end device now. Just plug in a standard, straight RJ45 Splitter and you instantly have 2 jacks.

Need to switch around peripheral sets? Just use a standard RJ45 Switch box as needed!

Atari SIO Jacks and plugs are hard to find and expensive. Replace them now.

--table---
EM0032 Replacement Jack, set 1
EM0033 Replacement Jack, set 5
EM0034 Replacement Jack, set 10
EM0035 E S1 to S2 Adapter- Male
EM0036 E S1 to S2 Adapter- Female
EM0037 SIO Plug to S2 Adapter
EP0045 RJ45 Straight jack Splitter


ORDERING(all funds US$, info for US and Canada only):
By PAYPAL Easy Click.
Mail payment to:
More Than Games
8207 Briarwood Lane
Austin TX 78757
